The current across a capacitor is equal to the capacitance of the capacitor multiplied by the derivative or change in the voltage across the capacitor. The very basic capacitor equations link the capacitance with the charge held on the capacitor and the voltage across the plates.

Derivation For Voltage Across A Charging And Discharging

Capacitors Learn Sparkfun Com

Shutting Down Safely With Capacitors Engineering Center

From the relations between charge q capacitance c and voltage v we can express the capacity charge formula as these three equations.

Voltage of a capacitor equation. If we assume that the potentiometer wiper is being moved such that the rate of voltage increase across the capacitor is steady for example voltage increasing at a constant rate of 2 volts per second the dvdt term of the formula will be a fixed value. As the voltage across the capacitor increases the current increases. This 063vs voltage point is given the abbreviation of 1t.

As the capacitor charges up the potential difference across its plates slowly increases with the actual time taken for the charge on the capacitor to reach 63 of its maximum possible voltage in our curve 063vs being known as one time constant t. Return to basic concepts menu. According to the equation this fixed value of dvdt.

The first shows how to find the capacitance based on charge and voltage the second is the capacitor charge equation while the third is the capacitor voltage equation. In the next equation we calculate the current across a capacitor. At t 0 the voltage across the capacitor is zero and the voltage across the resistor is v 0.

With this assumption solving the differential equation yields. The resistance is 10 kw and the capacitance is 100 uf microfarads. Although the formula works quite well for current the starting and final values for current are actually derived from the capacitors voltage so the calculating voltage is a more direct method.

The initial current is then i0 v 0 r. To see how the current and voltage of a capacitor are related you need to take the derivative of the capacitance equation qt cvt which is because dqtdt is the current through the capacitor you get the following i v relationship. This equation can then be developed to calculate the work required for charging a capacitor and hence the energy stored in it.
